RDS3005P

L2 Unmanaged DIN Rail Mount Full Gigabit Ethernet Switch Supporting PoE

Return to List

Product Introduction

RDS3005P is a cost-effective 5 ports full gigabit unmanaged Ethernet switch with up to 4 x 10/100/1000Base-T(X) RJ45 PoE/PoE+ ports and 1 x 10/100/1000Base-T(X) RJ45 port. All ports on RDS3005P support MDI/MDIX auto detection. This switch accepts a wide voltage range of 44-53VDC and is made of IP40 galvanized steel. It also has a wide operating temperature range from -40°C to +75°C, which is suitable for the harshest of environments without the use of fans.

Request for a quotation

Specifications
Dimension
Ordering Information

Specifications

Table 1. General

Description
Support	Ø 4 x 10/100/1000Base-T(X) RJ45 PoE+ Ports, Max. 30w per port, 1 x 10/100/1000Base-T(X) RJ45 Port Ø All RJ45 Ports support auto-negotiation Ø Store & Forwarding
IP40 Galvanized Steel Enclosure
Operating Temp. Range: ‐40°C to +75°C
35mm DIN Rail Mount

Table 2. Technical Specification

Description	Specifications
10/100/1000Base‐T(X) RJ45	5 in total, 4 are PoE/PoE+ Ports, 1 is non PoE/PoE+ Port, All ports support Auto MDI/MDIX
LEDs	Power Supply Status, RJ45 Ports, PoE Status, Device Status
Technology
Switching Mode	Store - Forwarding
MAC Table	8K
Jumbo Frame	Up to 9216 Bytes
Latency	<10μs
Physical Characteristics
Enclosure	IP-40 Galvanized Steel
Dimensions (W x D x H)	27.5 (W) x 95 (D) x 122 (H) mm
Weight (g)	<1kg
Power
Input Power	MV：44-53VDC, via 4-pin terminal block
Power Consumption (Typ.)	<5W (w/o PoE Output)
Overload Current Protection	Present
Reverse Polarity Protection	Present

Table 3. Compliance Specifications

Type	Standards
Electromagnetic Emissions	FCC Part 15, CISPR (EN55022) class A,
Electromagnetic Immunity	EN 61000-4-2 (ESD), EN 61000-4-3 (RS), EN 61000-4-4 (EFT), EN 61000-4-5 (Surge) EN 61000-4-6 (CS), EN 61000-4-8
Shock	IEC 60068-2-27
Free Fall	IEC 60068-2-32
Vibration	IEC 60068-2-6
Environmental Protection	RoHS and WEEE Compliance
Operating Environment	-40oC to +75oC, No Fans
Storage Environment	-40oC to +85oC
Operating Humidity	5% - 95% (Non-condensing)
Warranty	5 Years
MTBF	>36 Years

Table 4. Standards and Management

Description	Specification
IEEE Standards	IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX IEEE 802.3ab 1000BASE-T(X) IEEE 802.3af/at Power Over Ethernet
RFC Compliance	RFC 4445 MDI

Description

Specification

IEEE Standards

IEEE 802.3 10Base-T

IEEE 802.3u 100Base-TX

IEEE 802.3ab 1000BASE-T(X)

IEEE 802.3af/at Power Over Ethernet

RFC Compliance

RFC 4445 MDI

Base	Power Supply	Mount	Ethernet PoE Port	Ethernet Port	Optional	Description
RDS3005P	MV	D	4PGRJ45	1GRJ45
RDS3005P	\|	\|	\|	\|		Base unit
	MV	\|	\|	\|		Dual Input 44~53VDC
		D	\|	\|		DIN Rail Mount
			4PGRJ45	\|		4 x 10/100/1000Mbit/s RJ45 PoE/PoE+ Ports
				1GRJ45		1 x 10/100/1000Mbit/s RJ45 Port
					C	Conformal Coating
					U	User Customization

Example Order Code: RDS3005P-MV-D-4PGRJ45-1GRJ45

Description: RDS3005P Industrial Unmanaged Full Gigabit Ethernet PoE Switch, Dual MV input 44-53VDC, 35mm DIN Rail Mount, 4 x 10/100/1000Base-TX PoE/PoE+ RJ45 Ports, 1 x 10/100/1000Mbit/s RJ45 Port.
